Description
The HPE Networking Instant On Access Points AP22D is an SMB-focused Wi-Fi CERTIFIED 6™ access point that provides reliable wired and wireless connectivity over a 2.5 GbE uplink port with a minimal device footprint. This access point can reduce device clutter while powering downlink devices such as IP Phones or receipt printers with 2x 15W of PoE (802.3af) and supporting 75+ wireless devices over 802.11ax Wi-Fi 6 with an aggregate wireless throughput of 1.7 Gbps. Easily manage the Instant On AP22D with the Instant On mobile app or portal to create guest and employee networks, govern access control lists, and set PoE schedules to customize power use. Make the most of your limited space in your small business by mounting the Instant On AP22D to a desk or wall with included mounting kits.
What is new supporting point:
Wi-Fi CERTIFIED 6™ wireless access point, with 2.5 GbE uplink port
2.5 GbE uplink port provides up to 2x more bandwidth than 1 GbE ports without the need for new Cat5/6(a) cables to be installed.
Four 1 GbE downlink ports that supply up to 2x 15W of PoE (802.3af).
Up to 1.7 Gbps aggregate wireless throughput.
What is new supporting point:
Wi-Fi CERTIFIED 6™ wireless access point, with 2.5 GbE uplink port
2.5 GbE uplink port provides up to 2x more bandwidth than 1 GbE ports without the need for new Cat5/6(a) cables to be installed.
Four 1 GbE downlink ports that supply up to 2x 15W of PoE (802.3af).
Up to 1.7 Gbps aggregate wireless throughput.
Key Features
- 2.4 GHz 574 Mbit/s
- 5 GHz 1200 Mbit/s
- Maximum data transfer rate: 1200 Mbit/s
- IEEE 802.11ax
- OWE, WPA2, WPA3
- Power over Ethernet (PoE)
- Antennas quantity: 2 Internal
Specifications
| Dimensions Weight | |
|---|---|
| Width | 86 mm |
| Height | 150 mm |
| Depth | 47 mm |
| Weight | 360 g |
| Antenna | |
| Antenna direction type | Semi Directional |
| Antenna type | Internal |
| Battery | |
| Product colour | White |
| Data transmission | |
| Maximum data transfer rate | 1200 |
| Design | |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Ethernet LAN (RJ-45) ports | 5 |
| Mounting | Gang wall box-mount kit or Desk-mount kit |
| Ethernet LAN features | |
| Cabling technology | 10 100 1000base T X |
| Ethernet LAN data rates | 1000 Mbit/s, 2500 |
| Features | |
| 5 GHz | Yes |
| 6 GHz | No |
| Depth | 47 |
| Height | 150 |
| I/O ports | 1x 2.5 GbE Base-T PoE Class 4/6 uplink 2x 1 GbE Base-T PoE Class 3 downlink 2x 1 GbE Base-T downlink DC power connector LED status indicators Reset/LED control button Kensington security slot |
| Maximum data transfer rate (5 GHz) | 1200 |
| MIMO | Yes |
| MIMO type | Multi User MIMO |
| Number of users | 75 |
| Power over Ethernet (PoE) | Yes |
| Security algorithms | Owe, WPA2, WPA3 |
| Network | |
| Networking standards | IEEE 802.11ax |
Extra Information
Brand:
HPE
Width:
86 mm
Height:
150 mm
Depth:
47 mm
Weight:
360 g
Antenna direction type:
Semi Directional
Antenna type:
Internal
Product colour:
White
Maximum data transfer rate:
1200
Cable lock slot:
Yes
Cable lock slot type:
Kensington
Ethernet LAN (RJ-45) ports:
5
Mounting:
Gang wall box-mount kit or Desk-mount kit
Cabling technology:
10 100 1000base T X
Ethernet LAN data rates:
1000 Mbit/s, 2500
5 GHz:
Yes
6 GHz:
No
Depth:
47
Height:
150
I/O ports:
1x 2.5 GbE Base-T PoE Class 4/6 uplink 2x 1 GbE Base-T PoE Class 3 downlink 2x 1 GbE Base-T downlink DC power connector LED status indicators Reset/LED control button Kensington security slot
Maximum data transfer rate (5 GHz):
1200
MIMO:
Yes
MIMO type:
Multi User MIMO
Number of users:
75
Power over Ethernet (PoE):
Yes
Security algorithms:
Owe, WPA2, WPA3
Networking standards:
IEEE 802.11ax
