Description
HPE Aruba Networking Instant IAP-204. 2.4 GHz, 5 GHz, Maximum data transfer rate: 867 Mbit/s, Ethernet LAN data rates: 10,100,1000 Mbit/s. Power over Ethernet (PoE). Product colour: White. Power consumption (max): 12.5 W
Key Features
- 2.4 GHz
- 5 GHz 867 Mbit/s
- Maximum data transfer rate: 867 Mbit/s
- IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3az
- Power over Ethernet (PoE)
- Antennas quantity: 2
Specifications
| Dimensions Weight | |
|---|---|
| Width | 150 mm |
| Height | 41.5 mm |
| Depth | 150 mm |
| Weight | 380 g |
| Antenna | |
| Antenna connector type | RP-SMA |
| Battery | |
| Product colour | White |
| Data transmission | |
| Maximum data transfer rate | 867 |
| Design | |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Ethernet LAN (RJ-45) ports | 1 |
| Operating relative humidity (H-H) | 5 - 95 |
| Operating temperature (T-T) | 0 - 40 |
| Storage temperature (T-T) | -40 - 70 |
| Ethernet LAN features | |
| Ethernet LAN data rates | 10, 100, 1000 Mbit/s |
| Features | |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Depth | 150 |
| Height | 41.5 |
| Maximum data transfer rate (5 GHz) | 867 |
| Modulation | 16-QAM, 256-QAM, 64-QAM, BPSK, CCK, QPSK |
| Package depth | 187 |
| Package height | 57 |
| Package weight | 550 |
| Package width | 190 |
| Power over Ethernet (PoE) | Yes |
| Security algorithms | Not supported |
| Network | |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3az |
Extra Information
Brand:
HPE
Width:
150 mm
Height:
41.5 mm
Depth:
150 mm
Weight:
380 g
Antenna connector type:
RP-SMA
Product colour:
White
Maximum data transfer rate:
867
Cable lock slot:
Yes
Cable lock slot type:
Kensington
Ethernet LAN (RJ-45) ports:
1
Operating relative humidity (H-H):
5 - 95
Operating temperature (T-T):
0 - 40
Storage temperature (T-T):
-40 - 70
Ethernet LAN data rates:
10, 100, 1000 Mbit/s
2.4 GHz:
Yes
5 GHz:
Yes
Depth:
150
Height:
41.5
Maximum data transfer rate (5 GHz):
867
Modulation:
16-QAM, 256-QAM, 64-QAM, BPSK, CCK, QPSK
Package depth:
187
Package height:
57
Package weight:
550
Package width:
190
Power over Ethernet (PoE):
Yes
Security algorithms:
Not supported
Networking standards:
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3az
